How Does PVD Coating Work? A Step-by-Step Surface-Finishing Guide
1. What Does “PVD Coating Work” Actually Mean?
“PVD coating works” = vacuum physics + nano-chemistry turning your substrate into:
-
2 500–3 500 HV hardness
-
0.04–0.08 friction vs. steel
-
1 000 °C oxidation resistance
-
REACH-compliant finish
All in ≤ 3 µm without dimensional change.
2. The 5-Step PVD Surface-Finishing Journey
| Step | Vacuum Level | Temp (°C) | What Happens | KPI |
|---|---|---|---|---|
| 1 Pre-clean | 10⁻³ mbar | 25 | Ar⁺ plasma removes oil, oxide | Contact angle ≤ 8° |
| 2 Bond Layer | 10⁻³ mbar | 200 | 50 nm Cr or TiN for adhesion | Calot thickness ±2 nm |
| 3 Deposition | 10⁻⁴ mbar | 150–500 | Magnetron sputter or arc evaporate | ±5 nm uniformity |
| 4 Post-Polish | Air | 25 | Ion-beam or CMP Ra ≤ 0.01 µm | Optional |
| 5 QA & Pack | Air | 25 | CT + nano-indent + salt-spray | CpK ≥ 1.67 |
3. 2024 Performance Benchmark – PVD vs Legacy Finishes
| Finish | Thickness (µm) | Hardness (HV) | Salt-Spray (h) | Max Temp (°C) | Cost / m² (USD) |
|---|---|---|---|---|---|
| Electroplated Ni | 25 | 700 | 48 | 300 | 2.5 |
| Spray Paint | 50 | 200 | 48 | 150 | 0.8 |
| Traditional DLC | 2 | 2 000 | 500 | 400 | 4.0 |
| HiPIMS TiAlCrN (PVD) | 2 | 2 900 | 1 200 | 1 000 | 3.2 |
| Filtered Arc ta-C (PVD) | 0.5 | 3 000 | 1 000 | 400 | 2.8 |
4. Three 2024 Case Studies — How PVD Coating Works in Real Life
Case 1 – EV Motor Lamination Die
-
Challenge: 0.35 mm electrical steel sticking at 400 °C
-
Process: Plasma clean → CrAlON 1.8 µm → a-C:H 50 nm
-
Outcome: Tool life 4× longer, scrap −40 %
Case 2 – Medical Staple
-
Challenge: 316L needs low-friction piercing
-
Process: ta-C 300 nm + Cr 30 nm bond layer
-
Outcome: Penetration force −25 %, CE mark granted
Case 3 – Smartphone EMI Shield
-
Challenge: 6 GHz EMI leakage in SiC inverter
-
Process: Ag/Ni/Cr 150 nm multilayer
-
Outcome: Shielding 85 dB @ 6 GHz, CISPR 25 passed
5. How Fast Does the PVD Process Run? (Timeline)
| Milestone | Lead Time |
|---|---|
| DFM + Quote | 24 h |
| Prototype (1–10 pcs) | 48 h |
| Validation (CT, salt-spray) | 5 days |
| Mass production | 7–10 days |
| Door-to-door delivery | 12 days total |
6. Global Standards & Sustainability
-
ISO 9001:2015 / IATF 16949 / ISO 13485
-
REACH, RoHS, FDA 21 CFR §175.300
-
Energy: 0.45 kWh per m²
-
Waste: Zero liquid effluent
7. FAQs – How Does PVD Coating Work on …?
Q: Can PVD coat plastics?
A: Yes—metallised PEEK, PEKK, LCP.
A: Yes—metallised PEEK, PEKK, LCP.
Q: Largest part?
A: 800 mm Ø × 1200 mm L.
A: 800 mm Ø × 1200 mm L.
Q: Minimum order?
A: 1 piece.
A: 1 piece.
8. How to Start Tomorrow
-
Email [email protected] with STEP/IGES.
-
State substrate, load, temperature, thickness budget.
-
Receive DFM + coating stack + quote within 48 h.
-
Approve → 3-day prototype → volume ramp.
